The dCache July news

Dear friends of dCache (and others),

before you all head into your deserved holidays, I would like to keep you updated on recent activities at dCache.org. The topics have been collected, talking to people during the July GDB and the subsequent POST STEP'09 meeting. Please let me know if I missed something.

So, enjoy your last summer before LHC data taking and take care

Patrick and the dCache team.

New dCache Release Policy

dCache.org is introducing an important change in its release policy. As many other software projects, we are moving away from feature driven releases towards time based releases. This essentially means that we will tell you more precisely when the next release will be available, but no longer exactly which features will be made available within that version. Pros and cons of this approach are nicely covered by an oral presentation and by the PhD thesis of former Debian project lead Martin Michlmayr. The advantages for the dCache project mainly are that

we can ease the synchronization process between dCache and our distributers, that
sites can plan well ahead for system upgrades and that
releases are not infinitely postponed by waiting for promised features, which may be delayed for whatever reason.

On that topic, dCache is preparing for a "Golden Release" (1.9.5). As you may already guess, this Golden Release is going to be supported throughout the entire first LHC run-period and, as usual, no new features will be added to this release to ensure stability. However, we will of course continue to publish new releases with new features. It's up to the site to decide either to stay with the Golden Release or to follow up on the feature branch. Maybe our friends from WLCG do have an opinion here as well.

Release dates and features

The 1.9.3 release is out since July 1. As usual, NDGF already deployed this version ahead of time. No problems have been reported. Please make yourself familiar with the release notes. You will find that they provide a very useful matrix on head node and pool node release compatibility. 1.9.3 is the first dCache version allowing file system Access Control Lists (ACL's). On that topic the release notes provide more insights as well. Presentations have been given on gPlazma and ACL's during the dCache workshop in Aachen.
The release date for 1.9.4 has been scheduled for the week of July 20th at which point in time we will also provide the date, the Golden Release will be published. 1.9.4 is a more technical release, containing changes not visible to the user or system administrator. It might contain the Tape System Protection feature (see below), but this is not entirely clear yet. (See chapter on the dCache release policy). BTW : The 1.9.0 release branch is no longer supported.

Tape System Protection

Initially dCache has been designed to be a disk cache in front of a Tape Storage System, moving files onto the tape-backend and restoring them when needed. Those operations are handled transparently to the user. The downside of this approach is that a simple read of a file, not being on disk, automatically triggers a tape operation. As tape operations are expensive and may interfere with storing RAW data, coming from the Tier 0, this feature had to be reviewed. As a result, it has been agreed with the experiments that no non-production user should be allowed to trigger such a tape operation. dCache is now implementing a first version of such a protective mechanism. A dCache system administrator may specify a set of DN/FQAS's which are allowed to trigger tape read accesses for files not being available on disk. Users, requesting tape-only files, and not being on that white list, will receive a permission error and no tape operation is launched. Further details will be provided as soon as available. The feature might be in 1.9.4 but certainly will be part of the Golden Release (1.9.5).

The Chimera file system and the pnfs-to-chimera migration.

Chimera is the next generation dCache file system engine, replacing PNFS. It has been build to overcome PNFS scalability issues, which some large sites already encountered in the past and possibly will, in the future. Beside performance and scalability, Chimera is addressing operational and maintenance issues. Because, other than PNFS, Chimera is storing its file system meta information in a regular SQL database, system administrators may run standard SQL queries to get detailed information on the file system content or status (e.g. quota, tape backend etc). Chimera is a must in case you want to use file system ACL inheritance and in case you would like to test the NFS4.1 functionality in dCache.
Beginning of 2009, the first Tier II migrated to chimera, followed by the NDGF Tier I (end of March) and more Tier II's subsequently. No Chimera related problem has been reported since. Please find a presentation of the NDGF Tier I Chimera upgrade by Gerd and Mattias and a tutorial given during the Aachen dCache workshop at our dCache documentation area.
Instructions on how to migrate to Chimera are provided in our wiki. Larger sites (e.g. Tier I's) may consider to talk to dCache.org in case they would like to upgrade to Chimera prior to the LHC run start. We could make sure that experts are available.

Copy Module versus Migration Module.

Occasionally, large quantities of files need to be moved (copied) between pools to either drain pool hardware or to manually optimize dCache accesses. In the past this has been done using the Copy Module. This component has been replaced by the Migration Module which is a subcomponent of a pool cell and is accessible via the command line interface. Typing 'help migration' in the pool CLI will provide more details. A chapter in The Book is in preparation and will very soon be available.

ROOT and dCap

The ROOT framework is providing a handler for the dCap protocol. (TDCap file). As dCap and ROOT are following different development/deployment cycles, it unfortunately happened that there have been ROOT versions not properly working with certain dCap versions. Especially the famous vector read feature, although implement by ROOT AND dCap, couldn't be used at all. With the most recent releases this problem is solved. (ROOT 5.22 or better 5.24 and dCap 1.9.x).
Using vector read, ROOT is able to read a set of non-continous portions of a ROOT data file within a single transaction, improving performance significantely. Vector read doesn't rely on the tuning of the dCap read ahead buffer as it makes use of the internal ROOT file structure. If vector read is NOT used, it is advisable to optimize the dCap read ahead buffer according to your file access profile. The default is set to 8K in the TDCap file. It can be changed by setting the DCACHE_RA_BUFFER environment variable. If you are using a customized ROOT version, which might have read ahead disabled, you may set 'DCACHE_RAHEAD=true' to override this behavior.

NFS 4.1

NFS 4.1 is the most recent member of the Network File System family. Other than its predecessors it supports managing highly distributed data. It recently became a standard and has been adopted by various prominent OS and Storage Solution vendors. With 1.9.3, dCache provides an interface to the NFS 4.1 protocol, not only for file name space operations but for data I/O operations as well. This allows dCache to be mounted by NFS4.1 enabled clients, on which users can browse the file system name space and directly access data files as from any other mounted file system. In case you feel a strong desire to help us testing NFS4.1, please get more information from our wiki wiki pages.

Contact
Patrick Fuhrmann, DESY, Notkestrasse 85, 22607 Hamburg, patrick.fuhrmann@desy.de
